Intercable

17190

AIS Cable Stripper for External Insulation

Designed for removing outer sheaths from Ø16–54 mm medium-voltage cables. Suitable for high-strength outer sheath materials such as HDPE. Supports longitudinal and circular cutting with adjustable cutting depth from 0.5–5 mm. Complies with EN 60900 insulation standards.

Product Features

Live-Line Use: Suitable for use on live components up to 1000V AC / 1500V DC.
HDPE Sheath Application: Designed for high-density polyethylene and other high-strength outer sheath materials.
Longitudinal and Circular Cutting: Supports cable-end stripping and mid-span window stripping on medium-voltage cables.
Adjustable Cutting Depth: Cutting depth from 0.5–5 mm can be adjusted according to sheath thickness.
Ratchet Feed System: Enables two-way longitudinal feed for more stable and low-effort operation.
100° Rotation for Circular Cut: A 100° tool rotation completes a full 360° circular cut.
Hook Blade Design: Helps remove the cut outer sheath.
Insulated Safety Design: Two-component handle complies with CEI / EN60900 standards; the tool head is fully insulated except for the blade.
Replaceable Insulated Blade: Easy maintenance and extended tool service life.
Tool Case Set: Supplied in a tool case as a 5-piece tool set.

Add to Inquiry

Model Specifications

Product Details

Technical Data

Product Specifications

Model 17190 medium-voltage cable sheath stripping kit for Ø 16–54 mm HDPE sheaths and MV cables, suitable for work on live parts up to 1000V AC / 1500V DC.

Model

17190

Packaging

Tool case

Total tools

5 pieces

Cable diameter range

Ø 16–54 mm

Insulation / stripping depth

0.5–5 mm

Applicable material

High-density polyethylene HDPE

Voltage rating

Up to 1000V AC / 1500V DC

Applicable cable

MV medium-voltage cable

Cutting types

Longitudinal and circumferential cutting

Circumferential cutting

100° tool rotation completes 360° ring cut

Longitudinal feed

Bidirectional feed via ratchet lever

Blade

Electrically insulated replaceable blade

Handle

Two-component handle, compliant with CEI / EN60900

Tool head insulation

Fully insulated tool head except for the blade

MV Cable Stripping Kit for Live-Parts Work

Suitable for work on live parts up to 1000V AC / 1500V DC, supporting cable end and mid-span sheath removal for medium-voltage cable installation and maintenance.

Features

Product Features

Designed for stripping HDPE sheaths on MV cables, combining live-parts work capability, longitudinal / circumferential cutting, and electrically insulated replaceable blades.

For Work on Live Parts

Suitable for work on live parts up to 1000V AC and 1500V DC, improving flexibility in special field conditions.

For HDPE Outer Sheaths

Suitable for high-density polyethylene HDPE outer sheaths on MV medium-voltage cables.

Longitudinal and Circumferential Cutting

Supports longitudinal and circumferential cutting for cable end or mid-span sheath removal.

100° Rotation for 360° Ring Cut

A 100° tool rotation completes a 360° circumferential cut, improving ring-cutting efficiency and ease of operation.

Bidirectional Longitudinal Feed

Bidirectional longitudinal feed is achieved through the ratchet lever, supporting sheath opening in different directions.

Insulated and Serviceable Design

Equipped with an electrically insulated replaceable blade; the two-component handle complies with CEI / EN60900, and the tool head is fully insulated except for the blade.

Applications

Suitable for HDPE cable sheaths, MV cable stripping, work on live parts, and cable processing requiring longitudinal and circumferential cutting.

MV Cable Stripping

Suitable for stripping MV cables with Ø 16–54 mm diameter and 0.5–5 mm insulation thickness.

HDPE Sheath Removal

Suitable for removing HDPE cable outer sheaths at cable ends or mid-span sections.

Live-Parts and Dual Cutting Work

Suitable for work on live parts up to 1000V AC / 1500V DC, with longitudinal and circumferential cutting capability.
